GENESIS

​

LENGTH: 35'

BEAM: 11' - 6"

DEPTH: 3'

HULL# EM700000825

​

Owner:

GRILLOT CONSTRUCTION, LLC

​

Hull and Structure:

• 35' x 11' - 6" x 3" Hull – The main hull dimensions.

• Two 35' x 3' x 3' Pontoons – Additional buoyancy or stabilization.

• 35' x 17' - 6" x 3' Pin Together – Suggests modular design with pin-joined sections.

• A36-USA 1/4 Steel – Material for the hull, indicating it’s heavy-duty steel.

Power & Control:

• 2025 Single Yamaha 250hp – Power source, a 250-horsepower Yamaha outboard engine.

• SeaStar Steering – Hydraulic steering for smooth control.

• Weathertight Console – A protected control station.

Electrical and Fuel:

• 2 Deep Cycle Batteries – For power storage.

• 20 Gallons Fuel / ELC Fuel Reader – Fuel capacity and monitoring.

• Stainless Steel/Fuel Fill – Stainless steel used for fuel systems for corrosion resistance.

• NOCO Battery Charger x 2 – Charging system for the batteries.

• 6" JACKPLATE – For adjusting the engine’s mounting height.

Safety & Structural:

• Two Watertight Bulkheads – For additional watertight integrity.

• 3 Compartment Bilge Pumps (1500-Gallon/Min) – Ensures water removal from the boat.

• Eye Level 11' – 0 – Likely referring to the height of the bridge or control station.

• 6" Yellow Safety Stripe with Non-Skid – For visibility and safety, especially in wet conditions.

• 2' Push Knees with 2" Rubber – Used for pushing or protection during operations.

• Headlog Recess Lug – 40,000 lbs capacity – Used for anchoring or securing the boat with significant weight capacity, or pulling.

Winches & Additional Equipment:

• Two ELC Winches, 6" (20'-0) Spuds – Heavy-duty winches for operations involving movement or positioning.

• Removable Engine Guard – A protective guard for the engine that can be removed when not needed.

• Upper Port Station – Likely a secondary control station located on the port side.

Other Features:

• Stainless-Steel Hardware – Durability and corrosion resistance across the boat's fittings and components.
